Is there any known issue with dedup on truenas core 13.0?

TrueNAS General
,
1

asking cos a rsync compare of two pools one with dedup enbled killed my system with OoSwap

2

There’s the general issue that dedup is a resource hog… Rsync would really, really require the whole DDT in RAM. How much RAM and storage do you have?

3

32GB RAM I have. no VM running

1 Like
4

Quadruple the amount of RAM, and you might have enough to begin to think about dedup.

3 Likes
5

Yea, we would recommend avoiding the old dedup wherever possible. It has a not so good reputation for a lot of reasons. We have a fast-dedup project in the works with OpenZFS that is expected to land in the fall 24.10 version of TrueNAS SCALE. That version of dedup is expected to be much safer to run in more memory constrained systems, will eject non-dedup-able blocks, etc. Its still actively being worked on with Upstream, but we expect things to merge and land in time for OpenZFS 2.3.

More information here:

1 Like
6

@elkmaster Can you run the command zpool status -D from a shell? This will generate a histogram of your deduplication tables, and show us just how much space is actually being saved (and at what cost to your memory.)

1 Like
7
dedup: DDT entries 93359872, size 820B on disk, 182B in core

bucket              allocated                       referenced
______   ______________________________   ______________________________
refcnt   blocks   LSIZE   PSIZE   DSIZE   blocks   LSIZE   PSIZE   DSIZE
------   ------   -----   -----   -----   ------   -----   -----   -----
     1    86.2M   10.4T   10.4T   10.4T    86.2M   10.4T   10.4T   10.4T
     2    2.66M    319G    317G    317G    5.47M    654G    650G    650G
     4     121K   11.0G   10.9G   11.0G     583K   53.0G   52.5G   52.9G
     8    5.75K    317M    302M    307M    60.6K   3.22G   3.06G   3.12G
    16      575   16.8M   14.9M   15.9M    12.2K    360M    318M    340M
    32    1.14K   52.0M   48.6M   49.4M    48.0K   2.03G   1.89G   1.92G
    64      564   65.8M   65.8M   65.8M    56.7K   6.71G   6.70G   6.71G
   128       28   1.86M   1.84M   1.88M    4.71K    326M    321M    329M
   256       12   1.02M    758K    773K    3.80K    309M    222M    227M
   512        2    144K    132K    134K    1.69K    118M    108M    109M
    2K        1     16K     16K   17.4K    3.25K   51.9M   51.9M   56.6M
    4K        1     16K     16K   17.4K    4.53K   72.5M   72.5M   79.0M
   64K        1    128K    128K    128K     112K   13.9G   13.9G   13.9G
 Total    89.0M   10.8T   10.7T   10.7T    92.6M   11.2T   11.1T   11.1T
8

So pulling this apart a bit:

dedup: DDT entries 93359872, size 820B on disk, 182B in core

This line shows the utilization of your deduplication tables, by multiplying “number of entries” by “size in core (memory)” we get:

16991496704 bytes = 15.8G of RAM

So you’re losing about half of your RAM just to index the deduplication tables.

Space savings is the bottom row of the table:

bucket              allocated                       referenced
______   ______________________________   ______________________________
refcnt   blocks   LSIZE   PSIZE   DSIZE   blocks   LSIZE   PSIZE   DSIZE
------   ------   -----   -----   -----   ------   -----   -----   -----
 Total    89.0M   10.8T   10.7T   10.7T    92.6M   11.2T   11.1T   11.1T

You’re saving 11.1T - 10.7T = ~400G of space, or a dedup ratio of about 1.04.

Put simply, dedup probably isn’t worth it here.

1 Like
9

And that’s probably largely applicable to most dedup settings in home NAS.

Still that leaves a problem here: The 16 GB DDT should fit in 32 GB RAM and leave enough for the system to operate (“no VM”). Why is it running out of swap?

10

So what can I do to provide more (debug)information for this ?
