Problem/Justification
Prometheus and Grafana are well know monitoring system. Now we do add an converter and mapper to scrape metrics for prometheus.
Impact
A user who want scrape truenas metrics can do it easily.
Advantage : no need to put converter somewhere for scrape metrics.
Disadvantage : truenas team must code it
User Story
can prometheus ingest data from graphite? If yes truenas can already add a graphite exporter. Another option would be intsead of prometheus to use the graphite exporter to influxdb and then to grafana.
The real problem right now is that the system provides too few metric data points—many indicators are missing.
A graphite exporter mapping file for truenas scale >23.10.1 metrics and some example grafana dashboards
Going forward from exporter configuration version 2.1, you must also use the Netdata configuration included in the repository to restore the pre‑25.04 metrics. Instructions are provided below. This action is taken since TrueNAS 25.04 dropped a lot of default metrics which doesn’t make sense for me.
No, you need a converter graphite to prometheus.
Something like that : GitHub - prometheus/graphite_exporter: Server that accepts metrics via the Graphite protocol and exports them as Prometheus metrics
You have right, very few data points.
But I have see in /etc/netdata/netdata.conf, you can enable more metrics.
I don’t understand why they have not implemented this netdata plugin : ZFS Pools | Learn Netdata.
Yes, I have see and test the work to suppoterino.
But do you think it is normal to do all this stuff for only scrape metrics ?
why in something like octoprint, 2 click and it is finnish ?
A 3D printer software (Octoprint) is more monitor friendly than a NAS pro software (TrueNAS), why ?
It seems to be due to licensing issues? Although I don’t know why netdata had to be chosen in the first place, and then some things started being removed because of other problems
where have you see the licensing problem ?
But I think a serious software pro need metrics to be monitored.
A quick and dirty way to have prometheus metrics :
i have realized it with alloy running as app:
configs:
alloy_config:
content: |
// ===== SYSTEM METRICS EXPORT =====
prometheus.exporter.unix "integrations_node_exporter" {
procfs_path = "/host/proc"
sysfs_path = "/host/sys"
include_exporter_metrics = true
enable_collectors = ["systemd"]
disable_collectors = ["mdadm"]
}
discovery.relabel "integrations_node_exporter" {
targets = prometheus.exporter.unix.integrations_node_exporter.targets
rule {
target_label = "job"
replacement = "integrations/node_exporter"
}
rule {
replacement = env("INSTANCE_NAME")
target_label = "instance"
}
}
prometheus.scrape "integrations_node_exporter" {
targets = discovery.relabel.integrations_node_exporter.output
forward_to = [otelcol.receiver.prometheus.metrics.receiver]
job_name = "integrations/node_exporter"
scrape_interval = "15s"
}
// ===== CADVISOR (DOCKER CONTAINER METRICS) =====
prometheus.exporter.cadvisor "docker" {
docker_host = "unix:///var/run/docker.sock"
storage_duration = "5m"
}
discovery.relabel "cadvisor" {
targets = prometheus.exporter.cadvisor.docker.targets
rule {
replacement = env("INSTANCE_NAME")
target_label = "instance"
}
}
prometheus.scrape "cadvisor" {
targets = discovery.relabel.cadvisor.output
forward_to = [prometheus.relabel.cadvisor_fix_instance.receiver]
job_name = "integrations/cadvisor"
scrape_interval = "15s"
}
// ZUSÄTZLICHER RELABEL STEP für cAdvisor
prometheus.relabel "cadvisor_fix_instance" {
forward_to = [otelcol.receiver.prometheus.metrics.receiver]
// instance Label überschreiben falls vorhanden
rule {
replacement = env("INSTANCE_NAME")
target_label = "instance"
}
}
// ===== ALLOY SELF METRICS =====
prometheus.exporter.self "integrations_agent" { }
discovery.relabel "integrations_agent" {
targets = prometheus.exporter.self.integrations_agent.targets
rule {
replacement = env("INSTANCE_NAME")
target_label = "instance"
}
rule {
target_label = "job"
replacement = "integrations/alloy"
}
}
prometheus.scrape "integrations_agent" {
targets = discovery.relabel.integrations_agent.output
forward_to = [otelcol.receiver.prometheus.metrics.receiver]
job_name = "integrations/alloy"
scrape_interval = "15s"
}
prometheus.scrape "smartctl" {
targets = [
{"__address__" = "192.168.0.209:9633", "instance"="storage"},
]
forward_to = [otelcol.receiver.prometheus.metrics.receiver]
scrape_interval = "15s"
job_name = "smartctl"
}
// ===== OTEL RECEIVER FÜR METRICS =====
otelcol.receiver.prometheus "metrics" {
output {
metrics = [otelcol.processor.attributes.metrics.input]
}
}
otelcol.processor.attributes "metrics" {
action {
key = "cloud.region"
value = env("CLOUD_REGION")
action = "upsert"
}
action {
key = "cluster"
value = env("CLUSTER_NAME")
action = "upsert"
}
// WICHTIG: instance nochmal forcieren
action {
key = "instance"
value = env("INSTANCE_NAME")
action = "upsert"
}
output {
metrics = [otelcol.processor.batch.default.input]
}
}
// ===== SYSTEM LOGS (JOURNAL) =====
discovery.relabel "journal" {
targets = []
rule {
source_labels = ["__journal__systemd_unit"]
target_label = "service_name"
regex = "(.+)\\.service"
replacement = "$1"
}
rule {
source_labels = ["__journal_priority_keyword"]
target_label = "level"
}
rule {
source_labels = ["__journal__transport"]
target_label = "transport"
}
rule {
replacement = env("INSTANCE_NAME")
target_label = "instance"
}
}
loki.source.journal "journal" {
max_age = "12h0m0s"
relabel_rules = discovery.relabel.journal.rules
forward_to = [loki.process.journal.receiver]
labels = {
job = "systemd-journal",
}
}
loki.process "journal" {
forward_to = [loki.write.logs_default.receiver]
stage.match {
selector = "{service_name=\"alloy\"}"
stage.logfmt {
mapping = {
timestamp = "ts",
log_level = "level",
message = "msg",
service = "service",
}
}
stage.timestamp {
source = "timestamp"
format = "RFC3339Nano"
}
stage.label_drop {
values = ["job"]
}
stage.static_labels {
values = {
job = "integrations/alloy",
}
}
stage.labels {
values = {
level = "log_level",
}
}
}
stage.match {
selector = "{transport=\"kernel\"}"
stage.static_labels {
values = {
service_name = "kernel",
}
}
}
}
// ===== DOCKER CONTAINER LOGS =====
discovery.docker "containers" {
host = "unix:///var/run/docker.sock"
}
loki.source.docker "containers" {
host = "unix:///var/run/docker.sock"
targets = discovery.docker.containers.targets
forward_to = [loki.process.docker_logs.receiver]
}
loki.process "docker_logs" {
forward_to = [loki.write.logs_default.receiver]
}
// ===== LOKI WRITE =====
loki.write "logs_default" {
endpoint {
url = env("LOKI_ENDPOINT")
headers = {
"X-Scope-OrgID" = "langerma",
}
}
external_labels = {
cloud_region = env("CLOUD_REGION"),
cluster = env("CLUSTER_NAME"),
instance = env("INSTANCE_NAME"),
}
}
// ===== TRACING =====
tracing {
sampling_fraction = 0.1
write_to = [otelcol.processor.batch.default.input]
}
// ===== BATCH PROCESSOR =====
otelcol.processor.batch "default" {
send_batch_size = 1000
send_batch_max_size = 1000
timeout = "200ms"
output {
traces = [otelcol.exporter.otlphttp.cloud_traces.input]
metrics = [otelcol.exporter.otlphttp.cloud_metrics.input]
logs = [otelcol.exporter.otlphttp.cloud_logs.input]
}
}
// ===== OTLP EXPORTERS =====
otelcol.exporter.otlphttp "cloud_traces" {
client {
endpoint = env("TEMPO_ENDPOINT")
headers = {
"X-Scope-OrgID" = "langerma",
}
}
sending_queue {
num_consumers = 30
queue_size = 1000
}
}
otelcol.exporter.otlphttp "cloud_metrics" {
client {
endpoint = env("MIMIR_ENDPOINT")
headers = {
"X-Scope-OrgID" = "langerma",
}
}
sending_queue {
num_consumers = 30
queue_size = 1000
}
}
otelcol.exporter.otlphttp "cloud_logs" {
client {
endpoint = env("LOKI_OTLP_ENDPOINT")
headers = {
"X-Scope-OrgID" = "langerma",
}
}
sending_queue {
num_consumers = 30
queue_size = 1000
}
}
// ===== OTLP RECEIVER =====
otelcol.receiver.otlp "local" {
grpc {
endpoint = "0.0.0.0:4317"
}
http {
endpoint = "0.0.0.0:4318"
}
output {
metrics = [otelcol.processor.batch.default.input]
logs = [otelcol.processor.batch.default.input]
traces = [otelcol.processor.batch.default.input]
}
}
services:
alloy:
command:
- run
- /etc/alloy/config.alloy
- '--server.http.listen-addr=0.0.0.0:12345'
- '--storage.path=/var/lib/alloy/data'
configs:
- source: alloy_config
target: /etc/alloy/config.alloy
container_name: alloy
environment:
CLOUD_REGION: somewhere
CLUSTER_NAME: somecluster
INSTANCE_NAME: somename
LOKI_ENDPOINT: https://someloki/loki/api/v1/push
LOKI_OTLP_ENDPOINT: https://someloki/otlp
MIMIR_ENDPOINT: https://somemimir/otlp
NVIDIA_VISIBLE_DEVICES: void
TEMPO_ENDPOINT: https://sometempo/otlp
TZ: Europe/Vienna
group_add:
- '568'
image: grafana/alloy:latest
network_mode: bridge
platform: linux/amd64
ports:
- '12345:12345'
- '4317:4317'
- '4318:4318'
privileged: True
pull_policy: always
restart: unless-stopped
stdin_open: False
tty: False
user: '0:0'
volumes:
- /proc:/host/proc:ro
- /sys:/host/sys:ro
- /:/host/root:ro
- /var/run/docker.sock:/var/run/docker.sock:ro
- alloy-data:/var/lib/alloy/data
version: '3.8'
volumes:
alloy-data: Null
x-portals:
- host: 0.0.0.0
name: Web UI
path: /
port: 12345
scheme: http
and also smartctl exporter:
services:
smartctl-exporter:
environment:
NVIDIA_VISIBLE_DEVICES: void
TZ: Europe/Vienna
group_add:
- 568
image: prometheuscommunity/smartctl-exporter:latest
network_mode: host
platform: linux/amd64
privileged: True
pull_policy: always
restart: unless-stopped
stdin_open: False
tty: False
user: '0:0'
x-notes: >
# iX App
## Security
**Read the following security precautions to ensure that you wish to continue
using this application.**
---
### Container: [smartctl-exporter]
#### Privileged mode is enabled
- Has the same level of control as a system administrator
- Can access and modify any part of your TrueNAS system
#### Running user/group(s)
- User: root
- Group: root
- Supplementary Groups: apps
#### Security option [no-new-privileges] is not set
- Processes can gain additional privileges through setuid/setgid binaries
- Can potentially allow privilege escalation attacks within the container
---
version: '3.8'
services:
smartctl_exporter:
image: prometheuscommunity/smartctl-exporter:latest
container_name: smartctl-exporter
network_mode: host
user: root
devices:
- "/dev:/dev" # Nur das NVMe-Gerät
restart: unless-stopped
## Bug Reports and Feature Requests
If you find a bug in this app or have an idea for a new feature, please file
an issue at
https://github.com/truenas/apps
x-portals:
- host: 0.0.0.0
name: Web UI
path: /metrics
port: 9633
scheme: http
maybe someone finds it useful: feedback very much appriciated
There is also SNMP. It’s a bit old fashioned but if you only need basic monitoring for pool health, cpu usage, network usage, disk temperatures, etc. it does the job.
